Ring Die Poultry Feed Processing Plant For Producing Poultry And Livestock Feed

    Buy cheap Ring Die Poultry Feed Processing Plant For Producing Poultry And Livestock Feed from wholesalers

    Buy cheap Ring Die Poultry Feed Processing Plant For Producing Poultry And Livestock Feed from wholesalers
    • Buy cheap Ring Die Poultry Feed Processing Plant For Producing Poultry And Livestock Feed from wholesalers

    Ring Die Poultry Feed Processing Plant For Producing Poultry And Livestock Feed

    Ask Lasest Price
    Brand Name : AIX
    Model Number : SZLH350capa
    Certification : CE ISO
    Price : usd 10000-100000 set
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 300 sets per month
    Delivery Time : 7-15days
    • Product Details
    • Company Profile

    Ring Die Poultry Feed Processing Plant For Producing Poultry And Livestock Feed


    Chicken Goat Cattle Feed Pellet Making Machine Line poultry feed processing plant


    SZLH-350 Ring Die Animal Feed Pellet Production Line Brief Specification:


    This type feed pellet production line can process all kinds animal feed,such as corn,soybean,wheat bran,crushed fish and other additives,etc,it is very suitable to produce pellet feed and premix/powder/mash feed for chicken,duck,rabbit,pig,fish, shrimp, cattle,cow,sheep feed,etc.Adopt automatic batching system and computer control system,easy to adjust feed formulation and feed material mix proportion.One time invest,life-long benefit,it is a best choice for feed pellet production with output 5t/h.


    Automatic Batching Feed Pellet Production Line Production Process Follows:


    1. Raw material storage system of manufacturing plant for animal feed:Vertical Silo,

    2. Pre-cleaning system of manufacturing plant for animal feed: Pre-cleaner;

    3. Crushing system of manufacturing plant for animal feed: Feed Hammer mill;

    4. Automatic batching or Dosing system for animal feed: Batch weigher, Rotary distributor, Batch bins;

    5. Mixing system of manufacturing plant for animal feed: Paddle mixer;

    6. Pelletizing system of manufacturing plant for animal feed: Pellet mill and steam boiler;

    7. Cooling system of manufacturing plant for animal feed: Pellet Cooler, cyclone;

    8. Crumbler system to broken pellet: Roller crumbler;

    9. Sieving system of manufacturing plant for animal feed: Rotary sifter;

    10. Packing system of manufacturing plant for animal feed: Automatic packaging scale.


    Ring Die Animal Feed Pellet Mill Machine Main Model:


    ItemTechnical parameters and performance index
    SZLH250SZLH320SZLH350SZLH400SZLH420SZLH508
    Capacity (t/h)0.5-12-52-73-123-144-20
    Power (Kw)Main machine15375575/9090/110110/132/160
    Screw feeder0.550.750.751.51.51.5
    Conditioner2.22.235.55.511
    Inner diameter of die (mm)φ250mmφ320mmφ350mmφ400mmφ420mmφ508mm
    Effective width of die (mm)120mm120mm120mm120mm120mm150mm
    Rotary(rpm)Die328328328248248248
    Screw feeder12-12012-12012-12012-12012-12012-120
    Conditioner300300300270270270
    Pellet size (mm)φ2—φ10mmφ2—φ10mmφ2—φ10mmφ2—φ10mmφ2—φ10mm
    φ2—φ10mm
